OverviewD-PV | Industrial drone
D-PV for specialized operations
Structures, large areas, and routine maintenance.
The D-PV combines a carbon-fiber and aerospace-aluminum structure, multi-system navigation, centimeter-level RTK positioning, and industrial protection logic for industrial maintenance missions.
Rated payload
60 kg
Maximum rated payload for the platform.
No-load endurance
45 min
Mission window for lighter-duty operations.
Full-load endurance
16 min
Flight time at maximum payload.
Positioning accuracy
±0.05 m
RTK precision with multi-constellation navigation support.
Specialized maintenance operations
Technical details
Structure
Carbon fiber and aerospace aluminum, 4-axis / 8-rotor
35 kg empty weight, 49-inch propellers, 2110 mm wheelbase, and a folding layout for transport.
Navigation
Industrial multi-system positioning
Combines GPS, BeiDou, Galileo, and GLONASS to cover large operational areas.
Safety
Built-in mission-protection logic
Return-to-home on signal loss, automatic landing on low battery, and resume-from-breakpoint are built in.
Mission scenarios
Mission scenarios
Large-scale maintenance operations.
Long-range, repetitive maintenance work.
Stable operation in demanding outdoor environments.
Operational resilience
Operational resilience
Folding structure simplifies deployment and transportation in the field.
Expanded temperature envelope supports harsh environments.
Automatic protection logic improves continuity and mission safety.
Technical details
D-PV | Industrial drone
Airframe material
Carbon fiber + aerospace aluminum
Powertrain
4-axis / 8-rotor
Propellers
49 in
Empty weight
35 kg
Wheelbase
2110 mm
Open dimensions
1660 x 1660 x 1100 mm
Folded dimensions
1165 x 1165 x 1100 mm
Flight altitude
5000 m
Operating temperature
-20°C to 60°C
Wind resistance
Level 7
Specialized maintenance operations
D-PV
